Crafty Carbon XR er en toppmodell med Öhlin´s dempere i begge ender. For deg som liker fart, flyt og morro fra start til mål.

Crafty Carbon er Mondrakers e-Enduro race maskin. I carbonutgave er den ca 1,5kg lettere enn i aluminiumsutgave. Jo fortere det går, jo mer ber sykkelen deg slippe opp. Zero suspension føles bunnløs samtidig som den er svært fintfølende i starten av vandringen. Med Bosch Smart System motor og den lekkert integrerte System Controlleren i topprøret har du full oversikt over modus og batteristatus med et øyekast. Enheten kan styres fra styret via den trådløse Mini Remote fjernkontrollen.

Høydepunkter:

• Bosch CX Performance Smart System motor med 85Nm
• Superlett Carbonramme
• Bosch System Controller og Mini Remote
• Öhlins RFX 38 M.2 170mm dempegaffel
• Maxxis Minion 29x2,6" dekk
• SRAM Eagle X01 drivverk tilpasset el-sykkel

SPESIFIKASJONER

• Ramme:Crafty Stealth Air full Carbon, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal non-removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers.
• Gaffel:: Öhlins RXF 38 M.2 29, 170mm, TTX18 Twin Tube cartridge, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, air preload, ramp chamber
• Bakdemper: Öhlins TTX Air 205X65mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, air preload. Trunnion top mount, 25x10mm bottom bushings
• Styrelager: Acros custom for 1-1/2" head tube, angular contact bearings 40x52x7, Internal cable routing
• Styre: Onoff Krypton Carbon 1.0, rise: 25mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore
• Stem: Onoff Krypton FG 30mm, CNC, 31.8mm barbore
• Setepinne: Fox Transfer Factory Kashima internal, diameter 31.6mm, S size: 363.5x125mm, M/L size: 418.3x150mm, XL size: 475.1x175mm
• Hjulsett/felger: Mavic E-Deemax 29, 30mm internal width, tubeless ready, 28 spokes
• Nav/aksling - Bak:Mavic, Boost 12x148mm, sealed bearings, IS 6 bolts
• Nav/aksling - Foran: Mavic, Boost 15x110mm, sealed bearings, IS 6 bolts
• Dekk:Maxxis Minion 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ protection, 120TPI, folding bead
• Bremser: SRAM Code RSC
• Bremseskiver: SRAM Centerline 200mm
• Krankarmer: Race Face Aeffect ebike, 165mm
• Kranklager: Integrert i motor
• Frontgir: N/A
• Bakgir: SRAM X01 Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1
• Grirkifter: SRAM GX Eagle
• Kassett: SRAM PG-1275, 11-50T, 12s
• Kjede: SRAM NX Eagle, 12s, Powerlock
• Pedaler: N/A
• Motor: Bosch CX Performance 85Nm Smart System
• Battery: Bosch Smart System 750Wh
• Controller: Bosch Smart System w/Mini Remote
• Vekt: 23,3kg
